Innovating your workplace.
10.1 inch Smart Operation Panel
1,000 sheet hybrid finisher
Built-in duplex unit
Human Detection Sensor
Intel processor inside
Scanner
ARDF: Max. 80 originals per minute
Printing Process
Dry Electrostatic Transfer System with Dual component Development: 4-Drum method
Control Panel
10.1″ Smart Operation Panel
First Page Out Time
Full colour: 7.1/7.1/5.7/4.5 seconds
B/W: 4.6/4.6/4.0/3.1 seconds
Warm-Up Time
25/25/24/24 seconds
Resolution
Maximum: 1,200 x 1,200 dpi/2bit
System Memory
Standard: 2 GB
Maximum: 4 GB
Maximum Copy Quantity
1,625/1,625/3,625/3,625 sheets
Duplexing
SPDF: Max. 110 (simplex)/180 (duplex) originals per minute
Document Feeder Type
Standard 220-Sheet SPDF with single pass color duplex scanning
Zoom Range
From 25{140682088ba6a0c03a08d2e412a9e5538045e1abf41a3c8572448d5aa1fef6ba} to 400{140682088ba6a0c03a08d2e412a9e5538045e1abf41a3c8572448d5aa1fef6ba} in 1{140682088ba6a0c03a08d2e412a9e5538045e1abf41a3c8572448d5aa1fef6ba} steps
Maximum Original Size
A3, A4, A5, B4, B5
Supported Paper Weights
52 – 300 g/m²
Standard Paper Capacity
Maximum: 1,625/1,625/3,625/3,625 sheets
Maximum Paper Capacity
Maximum: 1,625/1,625/3,625/3,625 sheets
Power Source
220 – 240 V, 50/60 Hz
Typical Electricity Consumption TEC
Typical Electricity Consumption): 1.2/1.3/1.8/2.7 kWh
Power Consumption
Maximum: 1,700/1,700/1,850/1,850 W Ready mode: Less than 47.3/47.3/55.1/55.1 W Sleep mode: Less than 0.93/0.93/0.89/0.89 W TEC
Dimensions W x D x H
With ARDF: 587 x 685 x 913 mm With SPDF: 587 x 685 x 963 mm
Weight
101.3/101.3/103.4/103.4 kg
